Model: NEMA52 Stepper motor-JK130H3P (1.2 degree)

General Specification:

Step Accuracy ------------------------------ ±5%
Resistance Accuracy ----------------------- ±10%
Inductance Accuracy ---------------------- ±20%
Temperature Rise -------------------------- 80°C MAX.
Ambient Temperature Range ------------- -20°C~ +50°C
Storage Temperature Range ------------- -30°C~ +60°C
Insulation Resistance ---------------------- 100M Ω MIN. 500V DC
Dielectric Strength ------------------------- 500V AC 1min
Radial Play --------------------------------- 0.02mm MAX. (450g Load)
End Play ------------------------------------ 0.08mm MAX. (450g Load)
Max. radial force --------------------------- 220N
Max. axial force ---------------------------- 60N

Electrical Specification:

Note: We can also manufacture products according to customer's requirements.

Dimensions:(Unit=mm)

Dimensions:

(Unit=mm)

3 Phase stepper motor driver Model:  JK3DM2207
